Key Technical Features
- 10-Point Capacitive Touch Interface: Features an industrial-grade, highly responsive touch panel that supports multi-touch gestures, allowing delegates to annotate documents, navigate complex software, and control meeting parameters with smartphone-like ease.
- One-Touch Sharing Logic: Equipped with a dedicated physical or touch-sensitive button on the aluminum top plate. Pressing this button triggers the central JAD-SERVER-E2S to capture the local HDMI/USB-C feed and push it to all other delegate screens and the main room projector.
- Ultra-Thin Display Engineering: The display housing is crafted from aircraft-grade aluminum with a thickness of less than 10mm, providing a sleek, modern aesthetic that does not obstruct the view of other participants.
- Motorized Tilt Adjustment: Once the screen reaches its full height, the mechanism automatically tilts to a pre-set ergonomic angle (adjustable between 0° and 30°) to ensure optimal viewing and touch comfort.
- Integrated Signal Switching: Built-in hardware scaling and switching allow the unit to handle multiple inputs (HDMI, VGA, and DisplayPort) with automatic signal detection, ensuring seamless transitions between different presentation sources.
Technical Specifications
| Feature | Details |
| Screen Sizes Available | 15.6″, 17.3″, 18.5″, 21.5″ (16:9 Aspect Ratio) |
| Display Resolution | 1920 x 1080 Full HD (FHD) |
| Touch Technology | Projected Capacitive (P-CAP) |
| Lifting Speed | ~4-6 seconds to full extension |
| Noise Level | < 30dB (Ultra-silent operation) |
| Video Inputs | 1 x HDMI, 1 x VGA, 1 x USB (for touch data) |
| Control Interfaces | RS-232, RS-485, and Dry Contact (Phoenix) |
| Power Supply | AC 110V—240V / 50Hz—60Hz |
| Surface Finish | Anodized Brushed Aluminum (Black or Silver) |
Key Functional Highlights
- Seamless Collaborative Workflow: The “One-Touch Sharing” feature eliminates the need for complicated software menus or external video switchers. A delegate can share their screen in under a second, keeping the focus on the discussion rather than the technology.
- Anti-Pinch Safety System: Integrated smart sensors detect obstructions during the lifting or lowering process. If the unit senses resistance, it immediately stops and reverses its direction to prevent injury or damage to laptops and stationery.
- Hardened Anti-Glare Glass: The screen is protected by high-transmittance, anti-glare tempered glass, reducing reflections from overhead office lighting and maintaining high visibility for cameras during televised sessions.
- Centralized Command Support: The JAD-LSDAD-F can be controlled individually via local buttons or globally via the JAD-CK100 Control Plate, allowing the moderator to raise or lower every screen in the room simultaneously.
- Energy Efficient Design: Features an intelligent power-sensing circuit that puts the display into deep sleep mode the moment it begins its descent, significantly reducing the building’s overall power consumption.
Installation Note
The JAD-LSDAD-F is designed for flush-mounting into premium wood, stone, or composite conference tables. Each unit includes a mounting flange that conceals the cut-out, ensuring a clean, architectural finish.
