Technical Specifications
| Feature | Details |
| Battery Type | High-Density Lithium-Ion |
| Capacity | 6400 mAh / 7.4V |
| Operating Time (Multimedia) | ≥ 20 Hours |
| Operating Time (Speech Only) | ≥ 28 Hours |
| Charging Time | Approx. 4.5–5 Hours for full charge |
| Compatibility | JAD-MAW-T Multimedia Series |
| Charging Interface | Specialized Contact-pin (Optimized for JAD-WCH1) |
| Lifecycle | > 500 charge-discharge cycles |
| Protection | Built-in Overcharge, Over-discharge, and Thermal protection |
Key Functional Highlights
- Enhanced Capacity: Boasting a 6400 mAh capacity, the WBTY3-A is optimized for the power-intensive requirements of multimedia units, including screen brightness and video processing.
- Intelligent Power Monitoring: The internal microprocessor communicates with the JAD-MAW-T unit to display accurate, real-time battery percentages and remaining runtime on the OLED/Touchscreen.
- Rapid-Swap Design: Features a secure, spring-loaded locking mechanism that allows technicians to swap batteries in seconds without the need for tools.
- Eco-Friendly & Durable: A sustainable alternative to disposable cells, designed to maintain over 80% of its original capacity after hundreds of full recharge cycles.
- Safe-Core Technology: Advanced circuitry monitors internal cell temperature and voltage to prevent overheating during rapid charging in the JAD-WCH1 Charger Box.
