Technical Specifications
| Feature | Details |
| Transmission Tech | 5G Dual-Band Wi-Fi (802.11n/ac) |
| Multimedia Display | 7-inch (or larger) HD Capacitive Touch Screen |
| Audio Sampling | 48kHz Uncompressed Digital Audio |
| Video Support | Real-time Video Stream Playback |
| Resolution | 1024 x 600 (High-Definition) |
| Security | WPA2-PSK AES 128-bit Encryption |
| Power Supply | JAD-WBTY1 High-Capacity Battery Pack |
| Operating Time | ≥ 20 Hours (Multimedia mode) / ≥ 24 Hours (Speech only) |
| Interface | Dual 3.5mm Jack + USB Data Port |
| Microphone | Pluggable Gooseneck with LED Ring Indicator |
Key Functional Highlights
- Paperless Interactive Experience: The large touch screen supports document browsing (PDF/images) and agenda management, significantly reducing the need for printed materials.
- Dual-Band Stability: Operates on the 5GHz frequency to ensure that heavy multimedia data and high-fidelity audio remain stable even in environments with high Wi-Fi density.
- Electronic Nameplate: Features a digital display on the rear of the unit to show the participant’s name and title, which can be updated remotely via the JAD-DCP2000-W controller.
- Voting & Sign-in: Integrated software supports electronic sign-in and multiple voting modes (Yes/No/Abstain, 1-5 Rating), with results displayed in real-time on the unit screen.
- Video Integration: Capable of receiving RTSP/RTMP video streams, allowing delegates to view the active speaker’s camera feed or a shared presentation directly on their unit.
