Key Technical Features
- Full HD Image Sensor: Equipped with a high-quality 1/2.8-inch CMOS sensor, supporting native resolution up to 1080p@60Hz. It ensures vivid color reproduction and exceptional clarity for both remote participants and local recordings.
- High-Ratio Optical Zoom: Available in 12x, 20x, and 30x optical zoom configurations, allowing the camera to capture wide-angle room views or tight close-ups of delegates in large auditoriums without digital pixelation.
- Silent & Smooth PTZ Mechanism: Utilizing a specialized step-driving motor mechanism, the CDC-H series provides extremely quiet and smooth panning and tilting. This ensures that camera movements do not distract participants during quiet, high-stakes sessions.
- Advanced Auto-Focus Technology: Features a leading auto-focus algorithm that ensures the lens reaches focus quickly, accurately, and stably—even when the camera is rapidly moving between presets.
- WDR & Low-Noise Performance: Integrated Wide Dynamic Range (WDR) and 2D/3D noise reduction technology ensure a clear image in rooms with challenging lighting, such as those with large windows or intense overhead LED panels.
Technical Specifications
| Feature | Details |
| Video Format | 1080p/60, 1080p/50, 1080p/30, 720p/60 |
| Optical Zoom | 12x / 20x / 30x (Model Dependent) |
| View Angle | 72.5° (Wide) — 6.3° (Tele) |
| Video Outputs | HDMI, 3G-SDI, USB 3.0, LAN (IP) |
| Control Protocol | VISCA, PELCO-D, PELCO-P, ONVIF |
| Preset Positions | Up to 255 Presets (via Remote/Controller) |
| Pan/Tilt Range | Pan: ±170°; Tilt: -30° ~ +90° |
| Network Protocol | RTSP, RTMP, HTTP, ONVIF (Supports H.264/H.265) |
Key Functional Highlights
- Seamless Tracking Integration: Specifically tuned for the JAD ecosystem. When a delegate activates their microphone, the CDC-H camera instantly receives the command to move to the assigned preset with millimetre precision.
- Multi-Interface Output: Supports simultaneous output via HDMI, SDI, and IP. This allows you to send a lag-free signal to a local Video Wall Processor while streaming directly to the network for remote viewers.
- PoE (Power over Ethernet) Support: Simplifies installation by allowing power, control data, and video streams to be carried over a single CAT6 cable, significantly reducing cabling costs in complex installations.
- Inverted Installation: Features an image-flip function, allowing the camera to be mounted traditionally on a desk/tripod or inverted on a ceiling bracket without affecting the orientation of the video feed.
- Web-GUI Management: Includes a built-in web server for remote configuration. Administrators can adjust exposure settings, white balance, and pan/tilt speed from any browser on the network.
System Implementation Note
For the most reliable “Hands-Free” conference experience, connect the JAD-CDC-H to the JAD-CATC-B AV Bridge. This setup enables the camera to act as a “Virtual Webcam” for Zoom or Teams while automatically switching focus based on who is speaking.
